- Stock: 1 remaining
- Brand: Ubiquiti
- Model: UDM-Pro-Max
- Weight: 4.70kg
- Dimensions: 44.24cm x 43.70cm x 28.56cm
- UPC: 810084695517
Add-on items
| Image | Product | Price | Quantity | Action |
|
Ubiquiti Networks Fiber Module, UACC-CM-RJ45-MG |
HK$778 HK$1000 |
- + |
Add To Cart |
|
Ubiquiti UniFi U7 Long-Range Wi-Fi 7 Access Point, U7-LR |
HK$1820 HK$1999 |
- + |
Add To Cart |
|
Ubiquiti Unifi Camera AI 360, UVC-AI-360 |
HK$4170 HK$4410 |
- + |
Notify Me! |
|
UBIQUITI UNIFI DAC CABLE 0.5M, UACC-DAC-SFP10-0.5M |
HK$179 |
- + |
Add To Cart |
Ubiquiti UniFi Dream Machine Pro Max (UDM-Pro-Max) — Flagship Cloud Gateway Built for Large Enterprises and High-Load Environments
Powerfully upgrade your enterprise core network! The UniFi Dream Machine Pro Max (UDM-Pro-Max) is a high-performance 10G Cloud Gateway designed specifically to handle complex, large-scale networks. It perfectly supports over 200 UniFi devices and more than 2,000 clients, delivering an IDS/IPS throughput of up to 5 Gbps to build an unbreakable and ultra-fast backbone network for you.
A perfect integration of formidable hardware performance and storage flexibility in one machine: featuring built-in 32 GB eMMC and a 128 GB SSD, and equipped with (2) 3.5" NVR HDD bays, drastically improving system operation fluidity and recording storage space. Paired with versatile 10G SFP+ and 2.5 GbE dual WAN interfaces, the UDM-Pro-Max is absolutely the top-tier hub solution tailored for modern high-bandwidth, high-density enterprise environments.
Enterprise-Grade Applications (Perfect for Enterprise)
Dual WAN Failover & 10G High-Speed Network
Equipped with 10G SFP+ and 2.5 GbE dual WAN interfaces, perfectly supporting automatic failover and load balancing to ensure a stable and uninterrupted enterprise network.
Dual-Drive NVR & Built-in SSD Storage
The built-in 128 GB SSD significantly enhances system response speed, and provides 2x 3.5" NVR HDD bays (supporting RAID 1) to perfectly meet the demands for long-term HD security recording.
Enterprise-Grade Security Protection (IDS/IPS)
Provides up to 5 Gbps of Intrusion Detection and Prevention (IDS/IPS) throughput, combining an application-aware firewall with content filtering for comprehensive network security.
Ultra-High Capacity & Management Performance
Equipped with a Quad-core ARM Cortex-A57 processor and 8GB of DDR4 memory, its formidable computing power can effortlessly handle 200+ UniFi devices and over 2,000 connected clients simultaneously.
Hardware Specifications
| Device Type | Enterprise 10G Cloud Gateway |
|---|---|
| Networking Interface |
LAN: (8) 1 GbE RJ45 ports, (1) 10G SFP+ port WAN: (1) 2.5 GbE RJ45 port, (1) 10G SFP+ port |
| Performance & Storage |
Processor: Quad-core ARM® Cortex®-A57 @ 2.0 GHz Memory: 8 GB DDR4 On-Board Storage: 32 GB eMMC + Built-in 128 GB SSD NVR HDD Bays: (2) 3.5" HDD bays (supports RAID 1) |
| Security & Throughput |
IDS/IPS Throughput: 5 Gbps Supports application-aware firewall and signature-based threat detection |
| Special Features | 1.3" LCM touchscreen, Bluetooth for management setup, Dual WAN failover and Load Balancing |
| Dimensions | 442.4 x 43.7 x 285.6 mm (Standard 1U rack-mountable) |
| Weight | 4.7 kg (10.4 lb) |
| Power Method | (1) 100-240V AC, 50/60 Hz universal input (1) USP-RPS DC redundant power input (11.5V DC, 8.7A) |
| Power Supply | AC/DC, Internal, 100W |
| Max. Power Consumption | 60W (excluding HDDs) |
| Certifications | CE, FCC, IC |
| Official Warranty | 2-Year Limited Carry-in Warranty |
Device Details and Appearance
Package Contents
