Ubiquiti UniFi Switch 16 PoE (USW-16-PoE) — Fanless 16-Port Layer 2 PoE Switch for SMBs
Bring a stable and quiet upgrade to your office network! The UniFi Switch 16 PoE (USW-16-PoE) is a managed 16-port Layer 2 Gigabit switch equipped with an innovative fanless silent cooling system. Supporting 802.3at PoE+ and Gigabit fiber uplinks, it perfectly integrates into various SMB and SOHO network environments.
It features 16 Gigabit RJ45 ports (including 8 with 802.3at PoE+ support) and 2 1G SFP fiber uplink ports. It provides a total PoE power budget of up to 42W, enough to easily power UniFi Access Points (APs) and IP Cameras. Combined with the built-in 1.3-inch touchscreen, network management has never been more intuitive and simple.
Perfect for Enterprise
8 PoE+ Ports & Fiber Uplinks
Equipped with 16 Gigabit RJ45 ports (including 8 with 802.3at PoE+ support) and 2 1G SFP fiber ports, providing a 42W total PoE budget to easily drive APs and surveillance equipment.
Rich Layer 2 Switching Features
Supports advanced Layer 2 protocols such as IGMP Snooping, STP/RSTP, Port Isolation, Voice VLAN, and LACP aggregation to meet enterprise network management needs.
1.3" LCM Touchscreen & AR
Features a built-in 1.3-inch color touchscreen. Paired with the UniFi Network mobile app's Augmented Reality (AR) feature, it visually displays port connection status and system information.
Ultra-Silent Fanless Compact Design
Adopts an innovative fanless cooling system for ultra-quiet operation. With a depth of only 200mm, it takes up minimal space and is ideal for any standard 1U rack or office desktop.
Hardware Specifications
| Device Type | Managed Layer 2 PoE Switch |
|---|---|
| Networking Interface |
1G RJ45: (16) 1 GbE (1G/100M/10M) 1G SFP Uplink: (2) 1G SFP *8 of the RJ45 ports support 802.3at PoE+ |
| Switching Performance |
Switching Capacity: 36 Gbps Non-Blocking Throughput: 18 Gbps Forwarding Rate: 26.78 Mpps |
| PoE Capability |
Total PoE Availability: 42W Max. PoE Wattage per Port: 32W (PoE+ 802.3at) |
| Special Features | 1.3" LCM color touchscreen, silent fanless cooling, UniFi Network AR management support, advanced Layer 2 switching protocols |
| Dimensions | 442 x 200 x 44 mm (Standard 1U rack-mountable, ultra-compact depth) |
| Weight | 2.8 kg (2.9 kg with rackmount brackets) |
| Enclosure Material | SGCC Galvanized steel enclosure and mount brackets |
| Power Method | (1) 100-240V AC, 50/60 Hz Universal Input |
| Power Supply | AC/DC, Internal, 60W |
| Max. Power Consumption | 18W (Excluding PoE output) / 60W (Including max PoE output) |
| ESD/EMP Protection | Air: ± 16kV, Contact: ± 12kV |
| Operating Environment | Temperature: -5°C to 40°C / Humidity: 10% to 90% (Non-condensing) |
| Certifications | CE, FCC, IC, Anatel |
| Warranty | 2-Year Limited Carry-In Warranty |
Device Details and Appearance
Package Contents
