- Stock: 2 remaining
- Brand: APC
- Model: SRT1000XLI
- Weight: 20.50kg
- Dimensions: 50.50cm x 8.50cm x 43.20cm
- UPC: 731304340270
Add-on items
| Image | Product | Price | Quantity | Action |
|
APC Smart UPS SRT Extended Run Battery, SRT48BP |
HK$4960 HK$5969 |
- + |
Notify Me! |
|
IEC C13 to UK BS1363 3-Pin Power Cord, 1.8Meters |
HK$58 |
- + |
Add To Cart |
|
|
IEC C13 to UK BS1363 3-Pin Power Cord, 3Meters |
HK$98 |
- + |
Add To Cart |
|
IEC C13 Socket to IEC C14 Plug Power Cord, C13-C14, 2Meter |
HK$98 |
- + |
Notify Me! |
APC Smart-UPS On-Line 1000VA/1000W 230V (SRT1000XLI) — Reliable Online Backup Power Built for Hong Kong Enterprises and Core Servers
Provide the most solid backing for your core network equipment and servers! The APC Smart-UPS On-Line Series (SRT1000XLI) features a high-density, powerful output capacity of 1000W / 1000VA and provides 6 IEC 320 C13 output receptacles. During unstable utility power or unexpected outages, it ensures continuous system operation with Double Conversion Online technology, Sine wave output, and a lightning-fast zero-millisecond (0 ms) transfer time, providing the purest power to prevent data loss and hardware damage.
This model features Scalable Runtime, supporting up to 10 external battery modules to meet high-demand endurance requirements. With the built-in SmartSlot intelligent expansion slot, IT personnel can add a Network Management Card (NMC) for remote monitoring. It is the ultimate power guardian for local corporate offices, data centers, and server rooms.
Localized Scenarios (Perfect for Hong Kong)
Double Conversion Online, Zero Transfer Time
Offers an ultra-wide input voltage range of 100-275V. Achieves 0 ms latency when switching from utility to battery power, perfectly protecting sensitive equipment in environments prone to voltage fluctuations, such as Hong Kong factories or older commercial buildings.
SmartSlot Intelligent Network Expansion
Built-in SmartSlot expansion slot, with an optional Network Management Card, allowing IT teams to easily perform remote monitoring and receive system alerts over the network.
High-Density 1000W Load Capacity
Features a unity power factor of 1.0 (PF=1), delivering up to 1000W of real output power. Easily supports multiple high-end computing devices and network switches within server racks.
Intuitive Multifunction LCD Display
Equipped with a high-resolution color LCD display that accurately shows real-time voltage, load capacity, battery health, and remaining runtime, making on-site status clear at a glance.
Detailed Hardware Specifications
| Output Specifications | |
|---|---|
| Output Power Capacity | 1000 Watts / 1.0 kVA |
| Nominal Output Voltage & Frequency | 230V (Configurable to 220V/240V) | 50/60Hz +/- 3 Hz (Sync to mains) |
| Topology & Waveform | Double Conversion Online | Sine wave |
| Output Connections | (6) IEC 320 C13 |
| Transfer Time | 0 milliseconds (Zero Transfer Time) |
| Input Specifications | |
| Nominal Input Voltage | 230V |
| Input Voltage Range (Mains operation) | 176 - 275 V (Full load) / 100 - 275 V (40% load) |
| Input Connection & Frequency | IEC-320 C14 | 40 - 70 Hz (Auto-sensing) |
| Battery & Communications | |
| Battery Type & Life | Maintenance-free sealed Lead-Acid battery (leakproof) | Expected life 3 - 5 years |
| Battery Expansion & Recharge Time | Supports up to 10 external battery packs (SRT48BP) | Typical recharge time approx. 3 hours |
| Communications & Management Interface | SmartSlot, USB, Serial (RJ45) |
| Control Panel & Audible Alarms | Multifunction LCD status and control console | Audible and visual alarms prioritized by severity for battery power/low battery |
| Physical & Environment | |
| Physical Dimensions (HxWxD) | 43.2 cm x 8.5 cm x 50.5 cm |
| Net Weight | 20.5 KG |
| Operating Environment & Noise | 0 - 40 °C | 50 dBA at 1 meter from unit |
| International Safety Certifications | CE, EAC |
| Hong Kong Warranty | 3 years repair or replace (excluding battery) and 2 years for battery |
Runtime Reference Table
| Load | 200W | 400W | 600W | 800W | 1000W (Max) |
|---|---|---|---|---|---|
| Estimated Time | Approx. 48 mins | Approx. 22 mins | Approx. 13 mins | Approx. 8 mins | Approx. 5 mins 30 secs |
Product Package Contents
(Standard equipment includes: UPS unit, Software CD, Communications cable, Documentation CD, Installation guide, Removable support feet, USB cable)
