QNAP TVS-675-8G NAS

Powered by the x86 architecture Zhaoxin KaiXian KX-U6580 8-core processor, the TVS-675 provides businesses with a modern 2.5GbE NAS solution to tackle everyday tasks like file backup/restore, and to boost team collaboration with higher productivity. Besides hardware advantages with built-in M.2 SSD slots for cache acceleration and PCIe expansion, the TVS-675 supports abundant business and media applications (including snapshot protection, virtual machines, cloud storage gateways, 4K HDMI display, and real-time transcoding) alongside expandable storage capacity and install-on-demand apps, making it a cost-effective and reliable data storage and media NAS.

Tech Specs:

Benefits:

• Up to 5 Gbps transfer speeds can be achieved by setting port trunking with the two built-in 2.5GbE ports.
• Install high-performance M.2 PCIe NVMe Gen 3 x1 SSDs or economical SATA 6Gb/s SSDs in the dedicated SSD slots for caching with improved random I/O or high-performance storage pools.
• Two PCIe Gen 3 slots allow for installing 2.5/5/10GbE adapters, QM2 cards, or QXP storage expansion cards.
• 4K media playback and real-time transcoding; directly output videos to an HDMI 2.0 display (up to 4K @60Hz).
• Supports storage for virtualization; hosts multiple virtual machines and containers to run a wide range of applications on one NAS device.
• Flexibly scale the total storage capacity to match business growth by connecting QNAP expansion enclosures.

Product Details:

High-performance multi-tasking with an 8 core 2.5GHz processor and up to 64 GB RAM
Powered by an x86 architecture Zhaoxin KaiXian KX-U6580 8 cores/8 threads 2.5GHz processor and 8 GB DDR4 memory (expandable up to 64 GB - 2x 32GB, dual channel support), the TVS-675 has enormous processing power to drive virtual machine performance and tackle complex multitasking workloads. AES-NI encryption support boosts encryption performance while also maintaining the security of your NAS data.

Test environment:
NAS: TVS-675-8G, QTS 4.5.2, LAN-10G2SF-MLX
Volume type: RAID5, 6 x Samsung 860 EVO 1T SATA HDD
Client PC: Windows Server 2016, Intel Xeon E-2124, 64GB RAM, QXG-10G2SF-CX4

Abundant I/O capabilities with PCIe expansion
The TVS-675 has two PCIe Gen 3 x4 slots that allow for installing various expansion cards for expanding application potential.

Extend hardware warranty up to 5 years
The TVS-675 is backed by a 3-year warranty at no additional cost. You can also purchase a warranty extension that extends your warranty coverage up to 5 years.

Package Contents:
