- Stock: 12 remaining
- Brand: Ubiquiti
- Model: U-POE
- UPC: 817882024969
Ubiquiti UniFi PoE Adapter (15W) (U-PoE) — Gigabit PoE Injector Designed for UniFi Devices
Perfectly supports your UniFi network devices! The UniFi PoE Adapter (15W) (U-PoE) is a standard PoE injector offering up to 15W of output, designed to reduce the load on PoE switches and provide Gigabit high-speed connections.
The device features comprehensive surge, peak pulse, and overcurrent protection mechanisms to safeguard your network equipment from sudden electrical damage. The unit is equipped with an RJ45 data input and a PoE output port, alongside a grounded power cord design and an LED status indicator for more stable and reliable power delivery.
Key Features
15W Stable PoE Power Delivery
Provides up to 15W of standard PoE output (48V DC), perfectly compatible with various 802.3af-supported UniFi APs and IP surveillance cameras.
Gigabit Network Connection
Equipped with Gigabit RJ45 data input and PoE output ports, ensuring high-speed network transmission without speed drops and reducing reliance on the power supply of existing PoE switches.
Comprehensive Current Protection
Built-in surge protection, peak pulse, and overcurrent protection mechanisms, supporting both common-mode and differential-mode protection, significantly reducing the risk of equipment damage from sudden current spikes.
Status Indicator & Safety Design
The device features an LED status indicator for quick power troubleshooting and includes an AC power cord with Earth Ground protection to ensure long-term stable operation.
Hardware Specifications
| Device Type | Gigabit PoE Adapter |
|---|---|
| Networking Interface |
Data In & PoE Out: RJ45 Shielded Socket Gigabit LAN Port: Yes |
| Power Output & Voltage |
Output Voltage: 48V DC @ 0.32A (Up to 15W PoE) Rated Voltage: 100–240V AC @ 50/60Hz |
| Power Specifications |
2-pair Powering: Pins 4, 5 (+) and 7, 8 (-) AC Connector: IEC-320 C6 (Power cord included) Input Current: 500mA Max. Inrush Current: <100A peak @ 25°C |
| Protection Mechanisms |
Surge Protection: Difference and common mode Clamping Protection: 11V Data, 60V Power Max. Surge Discharge: 1500A (8/20 μs) power Peak Pulse Current: 36A (10/1000 μs) data |
| Electrical Specifications |
Efficiency: 84.25+% Switching Frequency: 65 kHz Output Ripple: 200mV pp Line Regulation: ≤ 3% Load Regulation: ≤ 5% Response Time: <1 ns Shunt Capacitance: <5 pF data |
| Dimensions | 86 x 46 x 33 mm (3.4 x 1.8 x 1.3") |
| Weight | 100 g (3.5 oz) |
| Environment |
Operating Temperature: 0 to 40° C (32 to 104° F) Storage Temperature: -30 to 70° C (-22 to 158° F) Operating Humidity: 10 to 95% noncondensing |
| Certifications | CE, FCC, IC, UL, CCC (NDAA Compliant) |
| Manufacturer Warranty | 1-Year Limited Warranty |
Device Details & Appearance
